Khoom npe: 1 2835 LED Module 170 degree
Yam Tsis Muaj: DV-LSWM-1S2835-W-12-170
Kev piav qhia
Adopt 2835 SMD, qhov no yog lub teeb ua kom pom kev zoo hluav taws xob ntau, Kev tsim tawm 12V DC nkaus xwb, 0.5w txhua IP65 qib ntsuas dej, kev siv sab hauv tsev thiab sab nraum zoov, lub kaum sab xis ntawm 170 degrees, lub neej ntev, xws li 30,000ours.used rau hauv cov paib, ntawv acrylic.
Feature thiab Advantage
Peb ua tus tsim qhov ntsuas qhov siab, nws yog qhov rov qab lub teeb.
Put Input voltage yog 12V DC nkaus xwb.
Module This LED module yuav siv tau rau sab hauv tsev thiab sab nraum zoov, kawm qib dej yog IP65.
Lub kaum sab xis ntawm qhov qauv yog 170 qib
Mod 50modules hauv qhov siab. txhua qhov module tuaj yeem txiav.
Module Qhov LED qauv no tuaj yeem ua haujlwm los ntawm tsav tsheb dimmable.
◆ Lifespan ntau tshaj 30,000hours.
◆ 5 xyoo warranty.
Module tshwj xeeb los ntawm 2835SMD, nws yog lub teeb ua haujlwm siab. 110lm / W.
Lub sijhawm ua haujlwm tau luv, nws ua haujlwm tamsis tsis muaj kev ua kom sov
◆ Ultra-low teeb pom kev zoo yog qhov zoo ntawm LED no.
Txhua yam khoom siv yog ua raws RoHS cov qauv.
Thov
Tsim Rau Txee Npe Ntsuas
Tsim Kom Muaj Tsaj Channel
Giant Channel Daim Ntawv
Qhov tob | Qhov deb | Qhov ceev | Lub Cim Ntsuas | Luminous Siv Ncaus | Nto Ci ntsa iab Txawv Sib Txawv | Yam Ruam |
(hli) | (hli) | (pcs / m²) | (Lux) | (cd / m²) | Lub Teeb Qeb | |
D=40 | P=90,S=60 | 150 | 1600 | 480 | 5%-10% | Zoo |
D=60 | P=120,S=90 | 70 | 1200 | 340 | 5%-10% | Zoo |
D=80 | P=150,S=120 | 42 | 800 | 230 | 5% | Zoo tshaj plaws |
D=100 | P=180,S=150 | 30 | 500 | 150 | 5% | Zoo tshaj plaws |
Cov tsis
Qhov Coob | Lub Zog | Kev tsuj roj | Lub teeb ua hauj lwm zoo | Lm Flux | Xim | Xim Temp | Ua Haujlwm Temp | Lub kaum ntse ntse | Tus Nqi IP | Ntim | Warranty |
25.5 * 10.5 * 8.5MM | 0.55W | DC12V | 100lm / w | 55lm | Sov Dawb / Dawb Dawb / Txias Dawb | 3000-3500K/ 6000-6500K/ 9000-12000K | -20°C~+60°C | 170° | IP65 | 20pcs / sawb | 3 / 5- Lub kua muag |
Profile Daim Duab
Lub teeb ci tis& hom qauv kho qhov muag
Ntawv pov thawj
Packing& Kev Thauj Khoom
Qty ntawm lub hnab | Qty ntawm lub thawv | Qhov ntev | Lub cev hnyav | Khoom hnyav tag nrho |
(pcs) | (pcs) | (hli) | (kg) | (kg) |
200 | 4000 | 460*370*250 | 15 | 15.8 |
Cim npe nrov: 2835 LED module 170 °, tus neeg muag khoom, chaw tsim khoom, Hoobkas, customized, lag luam wholesale, yuav, nqe, pheej yig, hauv Tshuag, dawb qauv
